Working Principle of Vertical Split Case Pump
Vertical Split Case Pumps combine space efficiency with hydraulic balance through a vertically split casing and double-suction impeller. Core functionality:
Axial Force Neutralization
Dual-entry impeller cancels 98% thrust loads, eliminating bearing stress (±2% residual).
Compact Footprint
Vertical orientation saves 60% floor space vs. horizontal equivalents.
Top/Bottom Access
Bolted casing halves enable full rotor service without pipe disconnection.
High-Head Capability
Staged diffusers achieve ≤300 m head at 15,000 m³/h (ISO 5199).
Key Advantages of Vertical Split Case Pump
Space Dominance
0.6 m² base area – ideal for cramped pump rooms.
01
Maintenance Speed
Replace wear parts in <3 hours (70% faster than inline pumps).
02
Energy Efficiency
90% peak efficiency – 8% higher than end-suction designs.
03
Zero Cavitation
Low NPSHr (1.2 m) prevents vapor lock at 120% flow.
04
Smart Diagnostics
IoT vibration/temp sensors predict failures via 4–20mA/Modbus.
05
Vertical Split Case Pump Design Specifications
|
Component |
Technology |
Benefit |
|
Casing |
ASTM A890 Grade 5A Duplex Steel |
PN40; corrosion/erosion-resistant |
|
Impeller |
316L SS AI-optimized vanes |
93% efficiency; 60,000-hour life |
|
Shaft |
17-4PH SS + SiC journals |
0.02mm runout; API 610 VS3 compliant |
|
Bearings |
Angular contact pairs |
L10: 200,000 hrs; oil-mist lubricated |
|
Seals |
Cartridge double mechanical |
≤0.1 ppm emissions (ISO 21049) |
Vertical Split Case Pump Cost and Performance Comparison
|
Parameter |
Vertical Split Case |
Horizontal Split Case |
Vertical Turbine |
|
Floor Space |
0.6 m² |
2.8 m² |
1.1 m² |
|
Max Head |
300 m |
150 m |
600 m |
|
Maintenance Time |
3 hours |
2 hours |
6 hours |
|
Efficiency |
88–90% |
85–92% |
80–88% |
|
Retrofit Cost |
$$ |
$$$ |
$$$$ |
Vertical Split Case Pumps Applications
